neck type LGB3pc Mapleset-in neck

top/back/side Spruce top Maple backMaple sides

fretboard Bound EbonyAcrylic & Abalone block inlay

fret Medium fretsPrestige fret edge treatment

number of frets 22

bridge Ebony bridge

string space 10.4mm

tailpiece LGB300 tailpiece

neck pickup Super 58 (H) neck pickupPassive/Alnico

bridge pickup Super 58 (H) bridge pickupPassive/Alnico

factory tuning 1E, 2B, 3G, 4D, 5A, 6E

string gauge .011/.015/.022w/.030/.040/.050

nut Bone nut

hardware color Gold

NECK DIMENSIONS

Scale : 628mm/24.7"

a : Width 45mm at NUT

b : Width 58mm at 22F

c : Thickness 20mm at 1F

d : Thickness 22mm at 9F

Radius : 305mmR
