Features
• Amp simulation filters with balanced output
• Three amp EQ curves plus bright switch
• Multiple ¼” jacks for plenty of connectivity
• Compact – runs on 9 volts for pedalboards
Benefits
• Eliminates the need for having an amp on stage
• Eliminates bleed from stage going into audience
• Lets you record quietly using your favorite pedals
• Can be tailored to sound like three different amps
Cool Stuff
• Perfect for small venue gigs
• Combine with your stage amp for extra tone
• 0ms delay to wedge monitors and in-ears!
• Can use all three outputs at once

Specifications

Audio circuit type: Class-A BiFET input buffer with electronic frequency shaping circuitry
Frequency response: Shaped for guitar use
Dynamic range: 83dB to 100dB
Clip Level: > +5dBu
Intermodulation Distortion: >0.1 @ -15dBu Out
Output Impedance: 600 Ohms (XLR) 100 Ohms (1/4")
Noise: -78dBU
Maximum Input: > +5dBu
Features
180° polarity reverse, Ground lift, Speaker filter
Input Connectors: 1/4"
Output Connectors: 1/4" thru and amp tone output, XLR
Extras: Always on Tuner Output
General
Construction: 14-gauge steel chassis and outer shell
Size (L x W x D): 4.75" x 3.625" x 2" (121 x 92 x 51mm)
Power: 40mA, 9VDC (center pin negative)
Conditions: For use in dry locations only between 5°C and 40°C
Warranty: Radial 3-year, transferable
