Features

• Great-sounding, fl exible passive DI

• High performance custom-wound transformer

• XLR, 1/4”, RCA and 3.5mm inputs

• Built-in stereo to mono merge function

• -15dB PAD for wide range of input levels

• Transformer isolation eliminates ground loops

Applications

• Converts hi-Z consumer to low-Z mic-level

• Connect a stereo source to a mono channel

• Unbalanced audio from CDs, laptop, VCRs

• Balanced +4dB audio sources (ProAV1 only)

Cool stuff

• Like a Swiss Army knife for A/V systems

• Completely passive, no power needed

• Ultra-tough 14 gauge steel enclosure

• 3 year transferable warranty

Specifications

Audio circuit type: Passive, transformer based

Transformer: Eclipse ET-DB2, 12:1 ratio

Number of channels: Single channel (mono)

Frequency response: 20Hz ~ 18.5KHz (± 0.2dB)

Dynamic range: 128dB

Total harmonic distortion: 0.01% from 20Hz~20kHz @-10dB

Phase Deviation: 1° @ 100Hz; 8° @ 20Hz

Input Impedance: 140k Ohms, unbalanced

Output Impedance: 150 Ohms, balanced

Common Mode Rejection Ratio: 100dB @ 60Hz

Maximum Input: +18dB @ 20Hz

Features

Input pad, Mono Sum, Ground lift

Input Connectors: 1/4", RCA, 3.5mm TRS, XLR

Output Connectors: XLR

Extras: 1/4" thru, RCA thru

General

Construction: 14 gauge steel chassis & shell

Size (L x W x D): 3.25” x 5” x 1.875”

Power: Passive, no power required

Conditions: For use in dry locations only between 5°C and 40°C

Warranty: Radial 3-year, transferable
