Features
• Switchable impedance for all pickup types
• Variable low-cut fi lter to eliminate resonance
• 48 volt phantom powered - no batteries!
• Extra headroom delivers amazing sound
Applications
• Piezo equipped orchestral instruments
• Magnetic sound-hole pickups on acoustics
• Acoustic guitars with active preamps
• Passive and active electric bass guitar
Cool Stuff
• Compact design without too many controls
• Internal switching supply for more dynamics
• Lift the ground without losing phantom power
• Perfectly suited for virtually any instrument

Specifications

Audio circuit type: Proprietary analog circuit with low-noise FET op-amp
Frequency response: 20Hz ~ 20kHz
Dynamic range: 105dB
Gain: +4.6dB
Total harmonic distortion: 0.02%
Input Impedance: 10M/1M/220K-Ohms
Output Impedance: 200 Ohms - nominal
Equivalent Input Noise: -98dBu
Features
Input pad
Input Connectors: 1/4" hi-Z input
Output Connectors: XLR male output
General
Construction: 48V phantom - proprietary digital switching
Power: 48V phantom - proprietary digital switching
Conditions: For use in dry locations only between 5°C and 40°C
Warranty: Radial 3-year, transferable
