Specs:

- Neck Type: GRG7 / Maple Neck

- Top / Back / Body: Quilted Maple Art Grain (Basswood) Top / Poplar Body

- Fretboard: Bound Purpleheart Fretboard / White Dot Inlay

- Fret: Jumbo Frets

- Number of Frets: 24

- Bridge: F107 Bridge

- String Space: 10.5 mm

- Neck Pickup: Infinity R (H) Neck Pickup (Passive/Ceramic)

- Bridge Pickup: Infinity R (H) Bridge Pickup (Passive/Ceramic)

- Factory Tuning: 1E, 2B, 3G, 4D, 5A, 6E, 7B

- String Gauge: 0.009 / 0.011 / 0.016 / 0.024 / 0.032 / 0.042 / 0.054

- Hardware Color: Black

Neck Dimensions:

- Scale: 648 mm / 25.5"

- Width at Nut: 48 mm

- Width at 24th Fret: 68 mm

- Thickness at 1st Fret: 20.5 mm

- Thickness at 12th Fret: 22.5 mm

- Fingerboard Radius: 400 mmR

Controls:

- With the guitar held in the playing position, there is 1 knob and 1 switch along the lower edge of the body. Closest to the neck is the 5-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the 5-way pickup selector switch.
