Type:

End address condenser with interchangeable capsules

Frequency Response:

20Hz - 20KHz

Impedance:

85 ohms

Using Cardioid Capsule:

Sensitivity: -40dBV (10mV) @ 1 Pa

Self Noise: 23dB, A-weighted

Maximum SPL: 155dB, 20dB pad engaged

Using Omnidirectional Capsule:

Sensitivity: -36dBV (16mV) @1 Pa

Self Noise: 19dB, A-weighted

Maximum SPL: 154dB, 20dB pad engaged

Power Requirements:

Phantom P48, 2mA

Connector:

Three pin XLR type

Polarity:

Inward pressure on the diaphragm produces positive voltage on pin 2

Dimensions:

7/8” (22 mm) x 6 1/8” (156 mm)

Net Weight:

7.6 oz. (216 grams).

Included Accessories:

Shockmount, mic clip and windscreen
