SPECS
    neck type:     AZ Oval CRoasted Maple neck
    top/back/body:     Quilted Maple topAmerican Basswood body
    fretboard:     Roasted Maple fretboardMother of Pearl dot inlay
    fret:     Jumbo Stainless Steel frets
    number of frets:     22
    bridge:     Gotoh® T1502 bridge
    string space:     10.5mm
    neck pickup:     Seymour Duncan® Hyperion™ (S) neck pickupPassive/Alnico
    middle pickup:     Seymour Duncan® Hyperion™ (S) middle pickupPassive/Alnico
    bridge pickup:     Seymour Duncan® Hyperion™ (H) bridge pickupPassive/Alnico
    factory tuning:     1E,2B,3G,4D,5A,6E
    strings:     D'Addario® EXL110
    string gauge:     .010/.013/.017/.026/.036/.046
    nut:     Graph Tech® nut
    hardware color:     Chrome

NECK DIMENSIONS
   Scale ::         648mm/25.5"
   a : Width:         42mm at NUT
   b : Width:         56.4mm at 22F
   c : Thickness:         20.5mm at 1F
   d : Thickness:         22.5mm at 12F
   Radius ::         305mmR

OTHER FEATURES
   Recommended Case
   M300C
   Gig bag included
   dyna-MIX9 switching system w/Alter Switch
   Gotoh® MG-T locking machine heads
   Luminescent side dot inlay

Features
Roasted Maple fretboard
Heat-treatment provides a well-balanced attack and tone and a rich sustain. In order to achieve supreme neck grip comfort, the fretboard edge is finished with a smooth curve.

Luminescent side dot inlays
The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

Gotoh® MG-T locking machine heads
The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

Quilted Maple top / American Basswood body
The Quilted Maple top sonically enriches the response for picking and the American Basswood body delivers a natural and flat tone.

Oval C Roasted Maple neck
Heat-treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes.

Gotoh® T1502 tremolo bridge
The T1502 tremolo bridge features steel saddles and a die-cast zinc tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm.

dyna-MIX 9 switching system w/Alter switch
dyna-MIX 9 offers nine sound variations, and can easily switch between humbucker and single coil modes with just the mini switch. One mode is even able to simulate a humbucker sound from the combination of the 2 single coil pickups.

Seymour Duncan® Hyperion™ Pickups
Seymour Duncan® Hyperion™ Pickups feature a moderate output through Alnico-5 magnets to keep the clarity of the fundamental tone when using a distortion sound, and to deliver a clear pick attack. From treble to bass, the overall tonal balance is evenly adjusted., and works well with various effect pedals.

Ergonomic rear body contour
A shallow body back contour and a big forearm contour make the guitar body fit the player naturally, thus increasing playing comfort. The AZ body has a deep waist and different radii on each body edge curve, making it easier to play in both standing or sitting positions.

Super All Access Neck Joint
The Super All Access Neck Joint increases playability and allows for easy access to the higher frets.
