Components and construction

3.5-inch (89 mm) woven composite low-frequency transducer

1-inch (25 mm), ultra-low-mass, silk-dome, high-frequency transducer

Rear-firing acoustic port for superior bass-frequency reproduction

Optimized, resonance-suppressing internal bracing

User controls

High- and low-frequency tuning controls

Front-panel Volume control for speakers and headphone amplifier

Power and safety

50 watt (25W/side), Class AB biamplification

RF interference, output current limiting, over-temperature, transient, and subsonic protection

Amplifier “soft start” feature eliminates popping on power-up

Internal power supply with IEC connector

Power switch with on/off LED

Inputs and outputs

Balanced ¼-inch TRS, unbalanced 1/8-inch stereo, and RCA inputs

Integrated stereo headphone amplifier with front-panel 1/8-inch output

Technical Specifications

Inputs

1- Stereo 1/8"

2- Balanced ¼” TRS

2- Unbalanced RCA

Performance

Frequency Response 80 Hz - 20 kHz

Crossover Frequency 2.8 kHz

Amplifier Power 25W/speaker

LF Driver 3.5"

HF Driver 1” silk dome

Peak SPL (@ 1 meter) 100 dB

Input Impedance 10 kΩ

User Controls

Volume Range A-type taper

MF Control Variable (-6 to +6 dB, center 100 Hz)

HF Control Variable (-6 to +6 dB, center 10 kHz)

Protection

RF interference

Output-current limiting

Over-temperature

Turn-on/off transient

Subsonic filter

External mains fuse

Power

100-120V ~50/60 Hz or 220-240V ~50/60 Hz

Cabinet

Vinyl-laminated, medium-density fiberboard

Physical

Width 5.6" (141 mm)

Depth 6.4" (162 mm)

Height 8.3" (210 mm)
