76 keys (with velocity)

-Sound Generator
-Parts
8

-TONE
ZEN-Core
* ZEN-Core Tones can be imported and exported.

-Tones
3,800 tones or greater
95 Drum kits or greater

-Expansion
EXZ Series
* The expansion are rewritable internal sound generator memory.
You can download data from the Roland Cloud and write it via a USB flash drive into the internal memory.

-Preset Scene
128 scenes x 2 bank

-User Scene
128

-Scene Remain
Yes

-Favorite
128

-Effects
Multi-Effects: 8 systems, 93 types
Part EQ: 8 systems
Drum Part COMP: 6 systems
Insertion Effect: 1 system, 93 types
Chorus: 10 types
Reverb: 8 types
System EQ: 1 system
Mic Reverb: 8 types
Mic NS/Comp

-Vocoder
Band: 13
Type: Mono

-Step Sequencer
8 Tracks (per secne)
Maximum 64 steps
Recording Method: Realtime recording, Step recording, TR-REC
Editing Method: Step edit

-Audio File Player Section
Audio file: WAV, AIFF
File format: 44.1/48 kHz, 8/16/24 bits

-Other
- Rhythm pattern

- Arpeggio

-Chord Memory

-Controllers
Pitch Bend/Modulation lever
Sound Modified knob x 4
Slider x 4
2 x 4 Pads

-Display
Graphic color LCD (480 x 272 dots with backlight)

-Connectors
Headphones jack: Stereo 1/4-inch phone type
MAIN OUT jacks (L/MONO, R): 1/4-inch TRS type
Mic Input jack: 1/4 inch phone type/XLR type
External Input jack: Stereo miniature phone type
FOOT PEDAL jacks(HOLD, CONTROL)
MIDI connectors (IN, OUT)
USB MEMORY port: Type-A (Storage)
USB COMPUTER port: USB Type-C(R) (Class Compliant for Audio and MIDI/ Roland driver for Audio and MIDI)

-External Memory
USB Flash drive (sold separately)

-Power Supply
AC Adaptor
USB bus power supply (USB Type-C(R) port)
* External power supply from a USB Type-A port isn't available.

-Current draw
700 mA (AC adaptor)
2,000 mA (USB bus power supply)

-Power consumption when in OFF mode (when the power automatically turns off)
0.2 W

-Dimensions
JUNO-D7: 1,217 (W) x 324 (D) x 94 (H) mm
JUNO-D7: 47-15/16 (W) x 12-13/16 (D) x 3-3/4 (H) inches

-Weight
JUNO-D7: 6.8 kg
JUNO-D7: 15 lbs


-Accessories
Startup Guide
Leaflet “USING THE UNIT SAFELY”
AC adaptor (PSB-5U)
Power cord

-Options (sold separately)
Keyboard Stand:
JUNO-D7: KS-11Z, KS-13, KS-20X
Pedal Switch: DP series
Expression Pedal: EV-5
