Manage multiple audio sources and sets of monitor speakers, track using illegally loud headphone amplifiers, and talk back to your drummer—all from your desktop.

Specifications

Inputs and Outputs

2 Stereo pairs of ¼” TRS inputs

1 Stereo pair of RCA Aux inputs

1 Stereo S/PDIF coaxial (RCA) digital input (44.1/48/88.2/96 kHz)

3 Stereo pairs of ¼” TRS speaker outputs with level controls

1 Stereo pair of ¼” TRS Main outputs

1 Stereo pair of ¼” TRS Cue outputs

4 ¼” TRS screaming-loud stereo headphone outputs

Controls

Large Main level control

3 Individual Main Source (ST1, ST2, Aux) select switches

3 Individual Speaker Select switches

Cue section with Source select (ST1, ST2, Aux) and output-level control

Aux-S/PDIF Select switch

Aux Input level control

Main Mute, Mono, and Dim switches with variable Dim attenuation

Additional Features

8-segment color LED input meters with selectable reference level

Built-in electret-condenser talkback microphone with input-gain control and Talkback button

Convenient desktop design

Dimensions

Height 2.5” (63.5 mm)

Depth 8.5” (216 mm)

Width 9” (228.6 mm)
