32-bit field recorder

M2 Features

- Stereo 32-bit float recorder

- Newly designed stereo X/Y microphones provide unmatched frequency response and clarity

- Body construction, and specialized finish to reduce handling noise

- LCD screen with waveform display

- Easy-to-use front panel controls

- Mono mode for ENG application

- Onboard Normalization function

- 3.5mm headphone output

- Includes a newly designed mic clip to mount on a mic stand

- USB Microphone compatible with PC, Mac, iOS, and Android (48 kHz at 24 or 32-bit Float**)

- Use as a USB microphone and record to SD card simultaneously

- Runs on 2 AA batteries* (11 hour battery life)

Audio Results Guaranteed

The M2 MicTrak is Zoom’s latest innovation in portable recording. With its all-new X/Y mic capsule design and 32-bit float technology, the M2 MicTrak always gives you great sound in one take.

One Take is All You Need

The M2 captures clip-free audio, every time. With 32-bit float recording, there's no need to set gain. Whether you’re recording soft-spoken dialogue or the thunderous sound of drums, you’ll never miss out on the sound you need.

Capture All Of Your Live Performances And Rehearsals.

The M2 is built to provide studio quality sound every time you hit ‘record’.

Podcast From Anywhere

When you’re on the go, the M2 is the only recorder you’ll need to deliver crisp, clear dialogue, every time.

Breaking News Only Gets One Take

When you have just one opportunity to capture the story, the M2 will not let you down.

Super Low Handling Noise

The M2’s unique X/Y stereo mics, along with its specially designed glossy finish significantly reduces handling noise.

Super Low Handling Noise

Stereo and Mono Modes

Choose between recording in stereo or mono modes. Stereo is optimal for music performances while mono is perfect for recording interviews and dialogue.

Normalizing Function

The M2 includes a NORMALIZE function that will raise or lower the level of your records to optimize volume. This saves time and streamlines the editing process.

On-Board Monitoring

Look

- Keep an eye on your recording using the M2’s LCD screen with a real-time waveform display.

Listen

-Use the headphone output to monitor your recordings and use the on-board speaker for quick reference.

USB Mic with 32-Bit Float

Connect the M2 via USB when recording and streaming on PC, Mac, iOS and Android.

Mic Clip Included

Place the M2 on a mic stand for stationary recordings by using the included mic clip.

Plenty of Battery Life

11-hour AA battery life, secured with our new sturdy lock-system, ensures that the M2 is ready to record whenever you need it.

Using the M2 for Electronic News Gathering during a public interview

What’s in the Box

Here’s what’s included:

M2 MicTrak

Windscreen

Mic Clip

Quick Tour

Specs

Inputs

Built-in mic 90º XY stereo format

Directionality Unidirectional

Sensitivity −42 dB/1 Pa at 1 kHz

Maximum sound pressure input 135 dB SPL



Outputs

Phone/Line Out Jack

Connector Stereo mini jack

Maximum output level 20 ｍW + 20 ｍW (into 32Ω load)

Output impedance 10 Ω or less

Built-in speaker 500mW 8Ω mono speaker



Recorder

Recording format WAV

44.1/48/96 kHz, 32-bit float

Stereo/mono

BWF and iXML formats supported

Recording media 4–32GB cards compatible with the microSDHC specification

64GB–1TB cards compatible with the microSDXC specification



Display

96×64 LCD with backlight



USB

Connector USB Type-C

• Use a USB cable that supports data transfer.

USB Mic USB 2.0 High Speed

48 kHz

24-bit or 32-bit float

File transfer USB 2.0 High Speed



Power

2 AA batteries Alkaline, Lithium, or Rechargeable NiMH

AC adapter ZOOM AD-17: DC 5 V/1 A

• USB bus power is supported.



Estimated Continuous Operation Time Using Batteries

Alkaline batteries About 11 hours

NiMH batteries (1900 mAh) About 10.5 hours

Lithium batteries About 22 hours



Stereo recording, 48kHz/32-bit float, no headphones, display backlight off

These values are approximate.

Continuous battery operation times were determined using in-house testing methods.

They will vary greatly according to use conditions.

Power consumption 5 W maximum

Dimensions 221.5 mm (W) × 61.9 mm (D) × 59.3 mm (H)

Weight (including batteries) 204 g



Note: 0 dBu = 0.775 Vrms

* Batteries not included

** For Android, 32-Bit Float cannot be used with USB Microphone
