Crown - XLS 2502 Power Amplifier

Meet the new XLS DriveCore™ 2 Series

The next generation of XLS got a makeover with a sleek new look, a LCD display that is three times larger, and more DSP with higher capabilities. Like its predecessor, the new XLS is ultra-efficient with Crown’s patented DriveCore technology and can drive 2400W at 4O bridged with tons of headroom guaranteeing a clean, undistorted signal straight to your speakers. The XLS DriveCore 2 assures that you will be heard as you deliver a powerful, pure sound experience for any venue.

• Class D amp with Crown's ultra-efficient DriveCore technology weighs less than 11 lb (5 kg)


• Higher DSP capabilities: More control; has band pass filter per channel


• Increased lighting functionality; turn off all LED indicators except clip and thermal to reduce distraction in dark venues


• Selectable input sensitivity; 1.4Vrms and .775Vrms options so that amp can be driven at full power


• Set sleep mode after specified time without having to press a button


• Security setting disables menu buttons; menu locked/unlocked by entering combination


• System reset allows factory settings to be restored


• Remote power trigger


• Peakx™ Limiters provide maximum output while protecting your speakers


• XLR, 1/4", RCA inputs provide flexibility


• Integrated PureBand™ Crossover System for better performance and control


• Efficient forced-air fans prevent excessive thermal buildup


• Sensitivity: 1.4Vrms


• Frequency Response: +0dB, -1dB


• Signal to Noise: > 97dB (at .775Vrms sensitivity, 6dB lower)


• Intermodulation Distortion: < 0.3%


• Damping Factor: > 200


• THD: < 0.5%


• Crosstalk: At 1kHz: > 85dB, At 20kHz: > 55dB


• Dimensions: 19" (48.3 cm) x 3.5" (8.9 cm) x 7.7" (19.6 cm)

XLS 2502
Two-channel, 775 W @ 4 Ohms Power Amplifier
