Specifications

Audio circuit type: Passive, transformer based
Transformer: Eclipse ET-DB3, 12:1 ratio
Number of channels: 1
Frequency response: 20Hz ~ 20KHz (± 0.5dB)
Dynamic range: 115dB
Total harmonic distortion: 0.005% @ 1kHz
Phase Deviation: 3° @ 100Hz; 8° @ 50Hz
Input Impedance: 140k Ohms, unbalanced
Output Impedance: 1k Ohms, balanced
Maximum Input: +20dB
Features
Input pad, Ground lift
Input Connectors: 1/4"
Output Connectors: XLR
General
Construction: 14 gauge steel chassis & outer shell
Power: Passive, no power required
Conditions: For use in dry locations only between 5°C and 40°C
Warranty: Radial 3-year, transferable
